offset press

FSD47/56S(II)-NP FSD56S(II)-NP FSD47S(II)NP Maximum printing size 544×380mm 454×345mm Maximum paper size 560×390mm 470×365mm Minimum paper size 200×148mm 90×140mm Paper type 28g-250g/Number of inking rolls First printing unit: 11, with 2 forme rolls Second printing unit: 14, with 3 forme rolls Number of water rolls 4 in each printing unit (1 forme roll in each unit) Registering mechanism Roller type side lay Printing speed 2000-8000 sheets per hour Minimum number space Vertical number: 71mm longitudinally, 48mm transversely Horizontal number: 47mm longitudinally, 60mm transversely, gripper edge: 25mm Motor power Main motor1.5KW Air pump motor0.55KW Electric supply 220v/50HZ(220v/60HZ Operational) Machine size FSD56 series 2290L×1040W×1280Hmm FSD47 series 2290L×940W×1280Hmm Weight 1100KG 960KG Introduction: This is a new type of multifunctional offset press developed for high-grade color printing, hiberarchy text overprint, number printing, line die cutting etc to meet all kinds of complicated printing requirements, in addition to the functions ofour othersoffset presses, it also has the following features: 1.Two printing units and a number printing and die cutting unit are closely connected, so it has complete functions in color printing, featuring well arranged screen lines, clear images, bright colors, free from cross color, and high printing speed . 2.Independent paper feeding with small errors, ensuring overprint precision. 3.A set of movable water-ink rollers can ensure that the other printing unit will not be worn during single color printing. 4.Effective PS plate installation and rubber blanket cleaning space for convenient operation. 5.The machine with compact structure occupies a small area and the operation is flexible and convenient. 6.All printing work can be complete in one pass for paper thickness from 17g to 250g and for number printing with longitudinal and cross die cutting.
